HDRX12 Fiber
Rugged Dual CAT6 Router with fiber optic
The HDRX12 is a high-performance, ruggedized networking solution designed for mission-critical military applications. Built to withstand extreme conditions, this router ensures secure and reliable communication in the harshest environments.
HDRX12 routers are manufactured in the European Union and have sophisticated hardware tested in thousands of applications
Durability & operation
Operating temperature: -40 °C to 75 °C
Ingress Protection Rating: IP67
Material: Extruded aluminum housing and die-cast or milled aluminum panels
Dimensions & Weight
Weight: up to 1200 g
Dimensions: 206,3 x 87 x 210/239 mm
Color: RAL6031
*different color available
Output & Power
Ethernet: 10/100/1000MBps, 4xRJ45 (LAN), 1 x LC (WAN)
Input voltage range: 9 – 50 V DC, M12 A code 4 pin male
PoE (passive): 1 x port, Mode B, 9 – 50 V DC
I/O: 1 x Digital Input, 1 x Digital Output
Power consumption: Idle: < 4 W, Max: < 22 W
Mobile, Wireless, GPS
Mobile module: 2 x 4G LTE CAT6, N-TYPE
SIM switch: 2 x 2FF SIM and 2 x eSIM, auto-switching
WiFi: 2.4 GHz & 5 GHz, N-TYPE
GNSS: GPS, GLONASS, BeiDou, Galileo and QZSS, N-TYPE
